Di Log DL6799 CombiVolt 5 TRMS Voltage, Continuity & Current Tester

Di Log DL6799 CombiVolt 5 TRMS Voltage, Continuity & Current Tester

Product Code: DILDL6799

Price

£116.45 ex. VAT £139.74 inc. VAT

Available In 3-7 Days

Add To Favourites
Detailed Description

Key Features:

Meets safety and performance requirements of BS EN 61010-1
750V TRMS AC / 1000V DC voltage measurement
Single Pole Voltage Detection
Non-Contact Voltage Detector
Phase rotation test system
Single pole phase indication
200A TRMS AC /DC Current measurement
60M Ohm Resistance with Audible Continuity
Capacitance
GS38 shrouded probe tips
Bright LED Flashlight
Carry Case

DILDL6799 Datasheet.pdf

The NEW CombiVolt 5 is a five-in-one tester with a rugged, ergonomically formed housing for perfect handling. With a range of testing functions including TRMS AC/DC voltages, TRMS AC/DC current, Non-Contact & Single Pole Voltage detection and a multitude of other functions the CombiVolt 5 offers complete versatility to the Electrical Engineer. Fully conformant to BS EN 61010-1, 61010-2-032, CAT II 1000V & CAT III 600V

AC Voltage TrueRMS	0-750V AC
Typical Accuracy	+/- 1.2 % + 3 digits
Frequency	45 - 400Hz
DC Voltage	0 - 1000V DC
Typical Accuracy	+/- 0.8 % + 3 digits
Single Pole Indication	>100Vrms
Non-contact Voltage Detection	>100Vrms Distance <10mm
AC Current	200A
Typical Accuracy	+/- 2.5 % + 5 digits
Frequency	50 - 60Hz
DC Current	200A
Typical Accuracy	+/- 1.0 % + 2 digits
Continuity	0-600Ω Audible <100Ohms
Resistance	0.1 - 60MΩ
Typical Accuracy	Typical Accuracy
Capacitance	60.00nF - 60.00mF
Diode	6.000V
Power supply	2 x 1.5 V (AA) LR06 batteries
Dimensions	210 x 53 x 35 mm
Weight	164g (batteries Included)
