Martindale BZ701 Audible Socket Tester with Mains Polarity Check

The BZ701 Socket and Polarity Tester is a further development in our Socket Tester range. It incorporates all standard BZ101 indications for both correct wiring as well as 28 different fault conditions.

Overview:

The BZ701 can also check the polarity of the incoming supply via the Blue Polarity Touchpad on the front of the unit. Correct incoming supply polarity is indicated by the flashing green LED’s accompanied by the continuous buzzer.

Incorrect supply polarity will be indicated by the LED’s turning RED and a pulse tone on the buzzer. This will continue after the removal of the finger from the touchpad and confirming a need for further investigation.

The BZ701 has a standby mode which activates after 10 minutes. In this situation, the lights will extinguish and only the centre LED will flash AMBER. The tone will also sound every 5 seconds to alert the user.

Key Features:

• Incoming supply cross polarity test
• Quick & easy mains socket testing
• High/low voltage indication
• Red/Green LEDs and buzzer indicates 28 fault conditions
• N E L labelled LEDs quickly identify the source of common faults
• Tough sculpted design for easy removal
