Megger LRCD220 Loop and RCD Tester

Product Code: MEGLRCD220

Price

£650.00 ex. VAT £780.00 inc. VAT

In Stock

Add To Favourites
Detailed Description

Key Features:

RCD testing from 10 mA to 1000 mA
Extremely easy and safe to use
Built-in protective front cover
Tough Rubber armoured case
Weatherproof
3 year warranty
Comes with calibration certificate

*Important Calibration Information:
This instrument comes complete with the manufacturer’s calibration certificate. Please be aware that these certificates are generic and may also be time lapsed. If you would prefer a personalised full traceable calibration certificate applied to the equipment before dispatch, then please select this option from the drop-down menu above, an additional calibration charge will apply.

The Megger LRCD200 series is the latest generation of combined non-tripping loop tester and RCD test instruments that provide simple, affordable and flexible test tools for electrical contractors testing energised circuits.

All Megger LRCD200 series instruments are supplied with a calibration certificate.

Two instruments are available:

Megger LRCD210
This instrument provides three phase safe non-trip loop testing and 1/2I, I, and 5I RCD testing for standard, selective and DC RCDs. Suitable for domestic installers testing to UK Part P requirements.

Megger LRCD220
As the LRCD210 with the addition of 2 wire fast testing, plus phase to phase and phase to earth measurement.

Both instruments will not trip RCDs rated at 30 mA or
greater during loop testing, even electronic RCDs.

	Megger LRCD220
	Voltage Measurements	0 V - 500 V
	Voltage Accuracy	±2% ±2 digits
	Frequency Measurement Range	25Hz to 450Hz
	Frequency Accuracy	25.0Hz to 199.9Hz ±0.1Hz 200Hz to 450Hz ±1Hz
	Phase Rotation Indicator (LRCD220 only)	Three wire identification of phase rotation.
	Frequency	45Hz to 65Hz
	Loop Testing	Loop ranges (to EN 61557-3)
	No-Trip Loop Test (3 Wire, Line To Earth)	LRCD200/210 200V - 280 V 45Hz to 65Hz LRCD220 100V - 280 V 45Hz to 65Hz
	Nominal Test Current	15 mA
	Loop Accuracy	0.01 ½ - 9.99 ½ (±5% ±0.03 ½) 10.0 ½ - 99.9 ½ (±5% ±0.5 ½) 100 ½ - 999 ½ (±5% ±5 ½) 1.00 k½ - 2.00 k½ (±5% ±30 ½)
	Hi Current Line/Earth Loop Test (2 Wire, LRCD220 Only)	Yes
	Supply	100 V - 480 V
	Nominal Test Current	15 mA to 2.4 A
	Loop Accuracy	0.01½ - 9.99 ½ (±5% ±0.03 ½) 10.0½ - 99.9 ½ (±5% ±0.5 ½) 100½ - 999 ½ (±5% ±5 ½) 1.0 k½ - 2.00 k½ (±5% ±30 ½)
	Line/Line (LRCD220 Only) Supply	100 V - 480 V 45Hz to 65Hz
	Prospective Fault Current (PSCC)	Prospective fault current = Nominal supply voltage/Loop resistance Accuracy is derived from loop test 1 A - 199 A 1 A resolution 0.20 kA - 1.99 kA 10 A resolution 2.0 kA - 19.9 kA 100 A resolution
	RCD Testing	RCD Test Ranges (to EN61557-6) LRCD200/210 10mA, 30mA,100mA, 300mA, 500mA LRCD220 10mA, 30mA,100mA, 300mA, 500mA, 1000mA
	Supply Voltage	LRCD200/210 = 200 V - 280 V 45Hz to 65Hz LRCD220 = 100 V - 280 V 45Hz to 65Hz

Megger LRCD220
	Voltage Measurements	0 V - 500 V
	Voltage Accuracy	±2% ±2 digits
	Frequency Measurement Range	25Hz to 450Hz
	Frequency Accuracy	25.0Hz to 199.9Hz ±0.1Hz 200Hz to 450Hz ±1Hz
	Phase Rotation Indicator (LRCD220 only)	Three wire identification of phase rotation.
	Frequency	45Hz to 65Hz
	Loop Testing	Loop ranges (to EN 61557-3)
	No-Trip Loop Test (3 Wire, Line To Earth)	LRCD200/210 200V - 280 V 45Hz to 65Hz LRCD220 100V - 280 V 45Hz to 65Hz
	Nominal Test Current	15 mA
	Loop Accuracy	0.01 ½ - 9.99 ½ (±5% ±0.03 ½) 10.0 ½ - 99.9 ½ (±5% ±0.5 ½) 100 ½ - 999 ½ (±5% ±5 ½) 1.00 k½ - 2.00 k½ (±5% ±30 ½)
	Hi Current Line/Earth Loop Test (2 Wire, LRCD220 Only)	Yes
	Supply	100 V - 480 V
	Nominal Test Current	15 mA to 2.4 A
	Loop Accuracy	0.01½ - 9.99 ½ (±5% ±0.03 ½) 10.0½ - 99.9 ½ (±5% ±0.5 ½) 100½ - 999 ½ (±5% ±5 ½) 1.0 k½ - 2.00 k½ (±5% ±30 ½)
	Line/Line (LRCD220 Only) Supply	100 V - 480 V 45Hz to 65Hz
	Prospective Fault Current (PSCC)	Prospective fault current = Nominal supply voltage/Loop resistance Accuracy is derived from loop test 1 A - 199 A 1 A resolution 0.20 kA - 1.99 kA 10 A resolution 2.0 kA - 19.9 kA 100 A resolution
	RCD Testing	RCD Test Ranges (to EN61557-6) LRCD200/210 10mA, 30mA,100mA, 300mA, 500mA LRCD220 10mA, 30mA,100mA, 300mA, 500mA, 1000mA
	Supply Voltage	LRCD200/210 = 200 V - 280 V 45Hz to 65Hz LRCD220 = 100 V - 280 V 45Hz to 65Hz
