Chauvin Arnoux CA8345 Qualistar Power and Energy Quality Analyser P01160657

Chauvin Arnoux CA8345 Qualistar Power and Energy Quality Analyser P01160657

Product Code: CHACA8345

Price

£4250.00 ex. VAT £5100.00 inc. VAT

Available In 3-7 Days

Add To Favourites
Detailed Description

This instrument comes without current clamps

Easy to handle, the Qualistar CA8345 is intended for inspection and maintenance teams working on industrial or tertiary installations. It can be used to obtain a snapshot of the main power quality parameters and can be used on any type of installation.

Voltage quality diagnostics
Full compliance with IEC 61000-4-30 Class A Ed 3
Highly communicating instrument
Qualistar range of easy-to-use products
Alarms, recordings, transients, Inrush, etc.

The CA 8345 is a Class A Qualistar power and energy quality analyser

Like the Qualistar+ models, it is equipped with an intuitive HMI and remains simple to use. Multilingual online help can be displayed at any time on the large LCD colour touch screen. A virtual keyboard is available in all modes and is displayed automatically on the HMI as soon as input is required to:
- lock the configuration with a password
- type emails directly

Easy to handle, it is intended for inspection and maintenance teams working on industrial or tertiary installation. I can be used to obtain a snapshot of the main power quality parameters. The Qualistars can be used on any type of installation.
For greater safety, the CA 8345 automatically recognizes the type of current sensor connected.
The CA 8345 offers high measurement accuracy. It proposes numerous calculated values and several processing functions. It offers users all the measurements required for successful energy efficiency projects and electrical distribution monitoring. It is also possible to immediately find out the value of the electricity consumed by means of an electricity cost calculation.
The CA 8345 can display harmonics and interharmonics as required by IEC 61000-4-7 up to the 127th order.
At the same time, it detects the carrier currents flowing on the installation.
Flicker measurements are performed according to the IEC 61000-4-15 standard.
The CA 8345 monitors all the events on the network:

Trend diagram, variations of the signal parameters
Configurable alarms, with the possibility of sending users email alerts
2.5 µs transients
12 kV shockwaves lasting 500 ns
TrueInrush, with a pre-trigger, to capture the startups of all the loads….

A Monitoring mode can be used to record measurement campaigns for analysis according to EN50160.

Communication
In addition to SD cards and USB drives, it is possible to recover the measurements and communicate remotely with the CA 8345 using USB, remote links, Wifi (direct WAP or via server) or RJ45. An IRD server mode allows data extraction from anywhere in the world without threatening the security of the internet network.
The Power Analyser Transfer PAT3 software can be used to process the measurements made with the Qualistar Class A. It can be downloaded from our support site. The Qualistar CA 8345 is certified as compliant with Class A of the IEC 61000-4-30 ed3 standard

FREE DataView software

DataView is a powerful tool for configuration, transfer and processing of measurement data for an extensive range of Chauvin Arnoux measuring instruments. The DataView Suite groups the DataView report editor and the PEL Transfer, PAT, PAT2, Data Logger, GTC, GTT, ICT, DTR, SLII MEG and MOT application software. For the download, a software key will be requested. this key is attached to the CDrom you received following the DataView software purchase.

DataView v3.62.0016

Compatible instruments :

PEL 102, PEL 103, PEL 104, PEL 105, PEL 106 power and energy loggers;
F407 and F607 power and harmonics clamps;
C.A 8220 and 8230 single-phase power analysers;
Qualistar C.A 8331,8332, 8333,8334, 8335, 8435, 8436, 8336 and 8345;
C.A 6526, 6532, 6534, 6543, 6547, 6549, 6550 and 6555 megohmmeters;
C.A 6240, 6250, 6255 and 6292 micro-ohmmeters;
C.A 6470N, 6471 and 6472 earth testers;
C.A 6417 earth clamp;
DTR 8510 ratiometer for transformers;
Simple Logger II and L452;
C.A 1110, 1227, 1246, 1821, 1822, 1510,1823, 10101, 10141 physical measurement devices;
C.A 6116, 6116N and 6117 electrical installation testers
