Fluke 117 TRMS Digital Multimeter

Product Code: FLU117

Price
£247.00 ex. VAT £296.40 inc. VAT

In Stock


Add To Favourites
Detailed Description

Key Features:

  • VoltAlert™ technology for non-contact voltage detection
  • AutoVolt automatic ac/dc voltage selection
  • Low input impedance: helps prevent false readings due to ghost voltage
  • Large white LED backlight to work in poorly lit areas
  • True-rms for accurate measurements on non-linear loads
  • Measures 10 A (20 A overload for 30-seconds)
  • Resistance, continuity, frequency and capacitance
  • Min/Max/Average with elapsed time to record signal fluctuations
  • Compact ergonomic design for one-handed operation
  • Compatible with optional magnetic hanger (ToolPak™) for hands free operation
  • CAT III 600 V safety rated

*Important Calibration Information:
This instrument comes with a ‘manufacturer's certificate of conformity’. It is important to understand that this does NOT constitute a ‘traceable calibration certificate’. A certificate of conformity merely states that the equipment has been designed and produced to meet the requirements of its intended application.
Where calibration of an instrument is possible, we will offer this as a separately purchasable item and may be selected from the drop-down box above. You will be sent a full traceable calibration certificate produced in our laboratory and applied with your details as required.

CALIBRATION ISS DMM

The Fluke 117 compact True RMS multimeter is popular for use in demanding settings such as commercial buildings, hospitals and schools. It includes integrated non-contact voltage detection to help get the job done faster.

The compact Fluke 117 true RMS digital multimeter is optimized to help you keep commercial buildings, hospitals and schools running right.

The advanced features of the Fluke 117 help you get the job done, quickly and safely. Integrated non-contact voltage detection helps you identify energized circuits. The AutoV/LoZ function prevents false readings caused by ghost voltage. The Fluke 117 delivers true-rms ac voltage and current readings with 6000-count resolution. It provides Min/Max/Average readings and measures frequency and capacitance. The battery door is easy to access, so you and your Fluke 117 can stay on the job.

Fluke 117 multimeters are independently tested for safe use in CAT III 600V environments.

And check out other members of the Fluke 110 family: Fluke 113 Utility Multimeter, the Fluke 114 Electrical Multimeter, the Fluke 115 Multimeter and the Fluke 116 HVAC Multimeter with Temperature and Microamps.

The Fluke 117 Multimeter is Supplied With:

  • Fluke 117 Multimeter
  • Test Leads
  • Holster
  • 9V Battery
  • User Manual

Fluke 117 TRMS Digital Multimeter

Attribute Value
Multimeter Type Handheld
Absolute Maximum DC Current Measurement 10A dc
Absolute Maximum AC Current Measurement 10A ac
Absolute Maximum AC Voltage Measurement 600V ac
Absolute Maximum Resistance Measurement 40MΩ
Absolute Maximum DC Voltage Measurement 600V dc
Absolute Maximum Capacitance Measurement 9.999mF
Functions Measured AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
True RMS Yes
Application Commercial
Maximum Frequency 1kHz
Display Type LCD
Model Number p 117
AC Current Measurement Resolution 0.001A ac
DC Current Measurement Resolution 0.001A dc
Resistance Measurement Resolution 100mΩ
AC Voltage Measurement Resolution 0.1mV ac
DC Voltage Measurement Resolution 0.1mV dc
Capacitance Measurement Resolution 1nF
Dimensions 167 x 84 x 46mm
Safety Category Level CAT III
Battery Type 9V
Width 84mm
Battery Life 400 h
Weight 550g
Height 46mm
Best AC Voltage Accuracy ±1% + 3 Digits
Best AC Current Accuracy ±1.5% + 3 Digits
Maximum Operating Temperature +50°C
Safety Category Voltage 600V
Safety Category CAT III 600 V
Best Resistance Measurement Accuracy ±1.5% + 2 Digits
Minimum Operating Temperature -10°C
Best DC Voltage Accuracy ±0.5% + 2 Digits
Best Capacitance Measurement Accuracy ±1.9% + 2 Digits
Best DC Current Accuracy ±1% + 3 Digits
Length 167mm
