Beha-Amprobe KMP7010 Earth Resistance Test Kit
Product Code: AMPKMP7010
Available In 3-7 Days
Add To Favourites
Detailed Description
Key Features:
- Measures earth ground resistance - 3 point (fall of potential) or 2 point tests
- Voltage measurement prevents false measurements
- Test leads, auxiliary electrodes are included for a complete instrument
- Data hold
- Large, backlit display
- Built-in memory to store 20 measurements
- Designed to allow testing to BS7671 IEE 17th Edition regulations
- Low battery indication
- Safety CAT III 400V
*Important Calibration Information:
This instrument comes with a ‘manufacturer's certificate of conformity’. It is important to understand that this does NOT constitute a ‘traceable calibration certificate’. A certificate of conformity merely states that the equipment has been designed and produced to meet the requirements of its intended application.
Where calibration of an instrument is possible, we will offer this as a separately purchasable item and may be selected from the drop-down box above. You will be sent a full traceable calibration certificate produced in our laboratory and applied with your details as required.
A properly functioning grounding system is a critical safety feature of an electrical system. It is used to mitigate the risk when exposed metal parts come in contact with dangerous voltages in the event an installation fails. The building structures are protected by grounding systems to divert energy of lightning strikes straight to ground. Connections to ground limit the build-up of static electricity when handling flammable products or when repairing
electronic devices.
Product details:
- Display LCD
- Meas. Principle Current-voltage measurement
- Earth Resistance 0.00Ω ~ 40.00Ω / 0.0Ω ~ 400.0Ω / 0Ω ~ 4000Ω
- Tolerance ±(2% rdg.+3 Digits)
- Data Memory 20 measurements
- Safety Complying with IEC61010/EN61010/IEC61557/EN61557/IEC61557/EN61557/BS7671 IEE 17th Edition regulations
- Overvoltage category CAT III / 400 V
- Pollution Degree 2
- Protection Degree IP40
- Power Supply 6 x 1.5V Alkaline Battery (AA)
- Dimensions 160mm x 101mm x 71mm
- Weight Approx. 500g (with batteries installed)
Robin-Amprobe Ground Resistance Testers are designed to measure resistance of the grounding systems to verify that the system has low enough resistance to provide protection for people, equipment and structures.
