DiLog DL6518 AC Leakage Clamp Meter

Product Code: DILDL6518

Price

£138.45 ex. VAT £166.14 inc. VAT

Available In 3-7 Days

Features:

• Shielded transformer jaw opens to 30mm
• 100μA high resolution reading range
• Dynamic range of 2000 counts full scale.

*Important Calibration Information:
This instrument comes with a ‘manufacturer's certificate of conformity’. It is important to understand that this does NOT constitute a ‘traceable calibration certificate’. A certificate of conformity merely states that the equipment has been designed and produced to meet the requirements of its intended application.
Where calibration of an instrument is possible, we will offer this as a separately purchasable item and may be selected from the drop-down box above. You will be sent a full traceable calibration certificate produced in our laboratory and applied with your details as required.

Accurate measurement of AC earth leakage with a resolution of 0.1mA enables the detection of nuisance tripping caused by faulty appliances or circuit faults resulting in current leakage to earth. The compact size of the DL6518 makes it ideal for hard to reach locations. The data hold enables readings to be captured when working in dimly lit areas.

DL6518 Specification:

Range Resolution Basic accuracy
200mA 01mA +/- 5% +8 digits
2A 1mA +/- 5% +10 digits
200A 0.1A +/- 2.5% +10 digits
Dimensions 182 x 61 x34mm
Weight 225g
