Fluke 17XX-CLAMP-ADPT-1V BNC Adapter for 1V Clamps 5363472

Fluke 17XX-CLAMP-ADPT-1V BNC Adapter for 1V Clamps 5363472

Product Code: FLUADPT1V

Price
£115.95 ex. VAT £139.14 inc. VAT

Available In 3-7 Days


Add To Favourites
Detailed Description

Key Features:

  • 7' (18 cm) long cable with 17XX connector and BNC connector
  • For current clamps featuring a maximum output of 1 V
  • Scale factor set in the instrument as mV/A
  • mV/A conversion for 17XX instruments
  • Current measurement using iron-cored current transformers
  • Enables DC measurements
  • DC power with instrument
  • Female BNC connector
  • Internal conductor protection
  • Label indicating adapter type
  • Protects your past investments in previously purchased current clamps from Fluke or other manufacturers
  • Gives the ability to use specialty current clamps
  • CAT IV, 600V and CATIII 1000 V rating according to IEC61010-2-30 appendix 2
  • Allows users to connect to a wider range of current clamps including measurement of DC for 177X products
  • Used to connect three-phase measurement equipment and in any electrical panel for connection of measurement equipment

Fluke 17XX-CLAMP-ADPT-1V Comes Supplied With:

  • BNC Adapter
  • Instruction Sheet
  • One-Year Warranty


Overview:

Compatible with current clamps featuring an output maximum of 1 V AC/DC, this BNC adapter allows the connection of AC or DC clamps to 17XX multimeters. In addition, this adapter consists of a cable with a plug that fits 17XX multimeters and a female BNC connector, allowing other current clamps connections with mV/A outputs.

Applications:

  • Users who need DC measurements (output of solar strings, inputs to DC-AC inverters, battery testing, etc.)
  • Users who aren't satisfied by the existing range of 17XX current clamps
  • Users who would prefer to use current clamps they already own
  • Consulting engineers and equipment manufacturers (panel builders) advising users on equipment installation
  • Facility managers
  • Safety, design, and senior electrical engineers
  • Electrical contractors and technicians
  • Electricians
